"""Caputo-Wismer material and sensor models."""
from __future__ import annotations
from collections.abc import Sequence
from dataclasses import dataclass
from math import isfinite, pi
from typing import Any
import numpy as np
def _positive_real(value: Any, name: str) -> float:
try:
result = float(value)
except (TypeError, ValueError) as error:
raise TypeError(f"{name} must be a real scalar") from error
if not isfinite(result) or result <= 0.0:
raise ValueError(f"{name} must be finite and positive")
return result
def _centre(values: Sequence[float], dimension: int) -> np.ndarray:
result = np.asarray(values, dtype=np.float64)
if result.shape != (dimension,) or not np.all(np.isfinite(result)):
raise ValueError(f"center must contain {dimension} finite coordinates")
return result
[docs]
def ring_sensor_locations(
num_sensors: int,
radius: float,
*,
center: Sequence[float] = (0.0, 0.0),
) -> np.ndarray:
"""Return uniformly spaced sensor centres on a two-dimensional ring."""
if (
not isinstance(num_sensors, int)
or isinstance(num_sensors, bool)
or num_sensors < 1
):
raise ValueError("num_sensors must be a positive integer")
radius_value = _positive_real(radius, "radius")
center_values = _centre(center, 2)
angles = 2.0 * pi * np.arange(num_sensors, dtype=np.float64) / num_sensors
return center_values + radius_value * np.column_stack(
(np.cos(angles), np.sin(angles))
)
[docs]
def sphere_sensor_locations(
num_sensors: int,
radius: float,
*,
center: Sequence[float] = (0.0, 0.0, 0.0),
) -> np.ndarray:
"""Return approximately uniform sensor centres on a three-dimensional sphere."""
if (
not isinstance(num_sensors, int)
or isinstance(num_sensors, bool)
or num_sensors < 1
):
raise ValueError("num_sensors must be a positive integer")
radius_value = _positive_real(radius, "radius")
center_values = _centre(center, 3)
indices = np.arange(num_sensors, dtype=np.float64)
z = 1.0 - 2.0 * (indices + 0.5) / num_sensors
azimuth = pi * (3.0 - np.sqrt(5.0)) * indices
radial = np.sqrt(np.maximum(0.0, 1.0 - z * z))
points = np.column_stack(
(radial * np.cos(azimuth), radial * np.sin(azimuth), z)
)
return center_values + radius_value * points
[docs]
@dataclass(frozen=True, slots=True)
class CaputoWismerMaterial:
"""One piecewise material in a Caputo-Wismer wave model."""
indicator: Any
wave_speed: Any
damping: Any
alpha: Any
[docs]
class SensorArray:
"""Gaussian volume sensors with a matching discrete adjoint."""
def __init__(
self,
space: Any,
locations: Any,
*,
width: float,
) -> None:
try:
import firedrake as fd
except ImportError as error:
raise RuntimeError(
"SensorArray requires an active Firedrake environment"
) from error
if space.ufl_element().family() != "Lagrange":
raise NotImplementedError(
"SensorArray supports continuous Lagrange spaces only"
)
if space.value_shape != ():
raise NotImplementedError("SensorArray supports scalar fields only")
mesh = space.mesh()
dimension = int(mesh.geometric_dimension)
if dimension not in {2, 3}:
raise NotImplementedError("SensorArray supports 2D or 3D meshes")
points = np.asarray(locations, dtype=np.float64)
if (
points.ndim != 2
or points.shape[0] == 0
or points.shape[1] != dimension
or not np.all(np.isfinite(points))
):
raise ValueError(
f"locations must have shape (num_sensors, {dimension})"
)
width_value = _positive_real(width, "width")
self._fd = fd
self.space = space
self.locations = points.copy()
self.locations.setflags(write=False)
self.width = width_value
self.dimension = dimension
coordinates = fd.SpatialCoordinate(mesh)
degree = int(space.ufl_element().degree())
coordinate_space = fd.VectorFunctionSpace(mesh, "CG", degree)
coordinate_values = np.asarray(
fd.Function(coordinate_space)
.interpolate(coordinates)
.dat.data_ro,
dtype=np.float64,
)
if coordinate_values.shape != (space.dof_dset.size, dimension):
raise RuntimeError(
"sensor coordinate and field layouts do not match"
)
offsets = (
coordinate_values[None, :, :] - points[:, None, :]
)
kernel_values = np.exp(
-0.5
* np.sum(offsets * offsets, axis=2)
/ width_value**2
)
trial = fd.TrialFunction(space)
test = fd.TestFunction(space)
mass_matrix = fd.assemble(
fd.inner(trial, test) * fd.dx,
mat_type="aij",
)
load = fd.assemble(test * fd.dx)
local_masses = kernel_values @ np.asarray(
load.dat.data_ro,
dtype=np.float64,
)
self._comm = mesh.comm
masses = np.asarray(
self._comm.allreduce(local_masses),
dtype=np.float64,
)
if np.any(~np.isfinite(masses)) or np.any(
masses <= np.finfo(np.float64).tiny
):
index = int(
np.flatnonzero(
(~np.isfinite(masses))
| (masses <= np.finfo(np.float64).tiny)
)[0]
)
raise ValueError(
f"sensor {index} has no resolvable support on the mesh"
)
kernel_values /= masses[:, None]
kernel_buffer = fd.Function(space, name="sensor_kernel")
row_buffer = fd.Cofunction(space.dual(), name="sensor_row")
row_values = np.empty_like(kernel_values)
for index, values in enumerate(kernel_values):
kernel_buffer.dat.data[:] = values
with (
kernel_buffer.dat.vec_ro as kernel_vector,
row_buffer.dat.vec as row_vector,
):
mass_matrix.petscmat.mult(kernel_vector, row_vector)
row_values[index] = row_buffer.dat.data_ro
self._kernel_values = kernel_values
self._row_values = row_values
self._adjoint_buffer = fd.Function(space, name="sensor_adjoint")
[docs]
@classmethod
def ring(
cls,
space: Any,
num_sensors: int,
radius: float,
*,
width: float,
center: Sequence[float] = (0.0, 0.0),
) -> SensorArray:
"""Construct a two-dimensional circular sensor array."""
return cls(
space,
ring_sensor_locations(
num_sensors,
radius,
center=center,
),
width=width,
)
[docs]
@classmethod
def sphere(
cls,
space: Any,
num_sensors: int,
radius: float,
*,
width: float,
center: Sequence[float] = (0.0, 0.0, 0.0),
) -> SensorArray:
"""Construct a three-dimensional spherical sensor array."""
return cls(
space,
sphere_sensor_locations(
num_sensors,
radius,
center=center,
),
width=width,
)
@property
def num_sensors(self) -> int:
return int(self.locations.shape[0])
[docs]
def sample(self, field: Any) -> np.ndarray:
"""Return the spatially averaged value recorded by every sensor."""
if field.function_space() != self.space:
raise ValueError("field must belong to the sensor function space")
local_values = self._row_values @ np.asarray(
field.dat.data_ro,
dtype=np.float64,
)
return np.asarray(
self._comm.allreduce(local_values),
dtype=np.float64,
)
[docs]
def adjoint_field(
self,
values: Any,
*,
out: Any = None,
) -> Any:
"""Map sensor values back to their normalized spatial kernels."""
coefficients = np.asarray(values, dtype=np.float64)
if coefficients.shape != (self.num_sensors,):
raise ValueError(
f"values must have shape ({self.num_sensors},)"
)
if not np.all(np.isfinite(coefficients)):
raise ValueError("sensor values must be finite")
result = self._adjoint_buffer if out is None else out
if result.function_space() != self.space:
raise ValueError("out must belong to the sensor function space")
result.dat.data[:] = coefficients @ self._kernel_values
return result
[docs]
def adjoint_covector(
self,
values: Any,
*,
out: Any = None,
) -> Any:
"""Apply the exact coefficient-space transpose of ``sample``."""
coefficients = np.asarray(values, dtype=np.float64)
if coefficients.shape != (self.num_sensors,):
raise ValueError(
f"values must have shape ({self.num_sensors},)"
)
if not np.all(np.isfinite(coefficients)):
raise ValueError("sensor values must be finite")
result = (
self._fd.Cofunction(self.space.dual(), name="sensor_covector")
if out is None
else out
)
if result.function_space() != self.space.dual():
raise ValueError("out must belong to the dual sensor space")
result.dat.data[:] = coefficients @ self._row_values
return result
